SDI-12 Data Logger

A rugged, weather-resistant SDI-12 data logger with a built-in solar charging system and rechargeable lithium-ion battery. Designed for long-term field deployments, it supports up to 10 SDI-12 sensors and provides reliable data logging without needing frequent maintenance.

Key Features

·         Supports up to 10 SDI-12 sensors.

·         No SDI-12 programming knowledge required — just connect the sensors and press a button to detect them via its software.

·         Includes SnapView software (Windows) for configuration, logging, and data export.

·         USB-to-SDI-12 bridge for data synchronization.

·         Short-circuit protection on the sensor port.

·         Uses the SDI-12 M! command to log up to 5 data points per sensor.

·         Powered by a 3.7 V, 3500 mAh 18650 lithium-ion cell, recharged via a built-in solar circuit.

·         Low-battery warning: battery monitoring via software; LED indicators for low power.

·         Memory capacity for 59,000+ scans (each scan up to 5 data points) before overwriting.

·         Enclosure is NEMA 4-rated, UV-resistant polycarbonate.

·         Operating temperature: –20 °C to +50 °C.

·         Comes with a micro-USB cable, a 45° terminal adapter, and a solar panel.
